Centralized logs with Grafana Loki + Promtail

Published on May 17, 2026

Centralize all your VPS logs in a single Grafana UI with Loki. Lightweight, performant, Prometheus-style queries (LogQL), and much less resource-hungry than ELK. The modern standard for multi-server setups.

Category: VPS Linux
Level: Advanced
Reading time: 6 min
Published: May 17, 2026

Introduction

With 1 VPS, grep /var/log/syslog is enough. At 3+ VPS, navigating between servers becomes painful. At 10+, it's impossible. Solution: centralize the logs.

Classic stack: ELK (Elasticsearch + Logstash + Kibana). Heavy, complex, RAM-hungry. Modern alternative: Grafana Loki:

Lightweight: indexes labels, not content → 10x less storage
Prometheus-style: same UX, same query language (LogQL)
Integrated with Grafana: one tool for metrics + logs
Open-source by Grafana Labs

This guide installs Loki on a central VPS + Promtail (agent) on each source VPS.

Prerequisites

1 "central" VPS for Loki + Grafana (1 GB RAM minimum)
N source VPS whose logs you want
Docker installed on the central VPS
Network between VPS (WireGuard recommended to not expose Loki publicly)

Step 1: Target architecture

   ┌──────────────────┐  ┌──────────────────┐  ┌──────────────────┐
   │ VPS Web 1        │  │ VPS Web 2        │  │ VPS DB           │
   │  + Promtail      │  │  + Promtail      │  │  + Promtail      │
   └────────┬─────────┘  └────────┬─────────┘  └────────┬─────────┘
            │                     │                     │
            └─────────────────────┼─────────────────────┘
                                  │
                          ┌───────▼────────┐
                          │  Central VPS   │
                          │  ┌──────────┐  │
                          │  │  Loki    │  │
                          │  └──────────┘  │
                          │  ┌──────────┐  │
                          │  │ Grafana  │  │
                          │  └──────────┘  │
                          └────────────────┘

Step 2: Deploy Loki + Grafana (central VPS)

sudo mkdir -p /opt/loki-stack
cd /opt/loki-stack
sudo nano docker-compose.yml

services:
  loki:
    image: grafana/loki:3.0.0
    container_name: loki
    restart: unless-stopped
    ports:
      - "3100:3100"
    volumes:
      - ./loki-config.yml:/etc/loki/local-config.yaml:ro
      - loki_data:/loki
    command: -config.file=/etc/loki/local-config.yaml
    networks:
      - loki-net

  grafana:
    image: grafana/grafana:latest
    container_name: grafana
    restart: unless-stopped
    ports:
      - "127.0.0.1:3000:3000"
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=AStrongPassword
      - GF_USERS_ALLOW_SIGN_UP=false
    volumes:
      - grafana_data:/var/lib/grafana
    networks:
      - loki-net
    depends_on:
      - loki

volumes:
  loki_data:
  grafana_data:

networks:
  loki-net:

Step 3: Minimal Loki config

sudo nano /opt/loki-stack/loki-config.yml

auth_enabled: false

server:
  http_listen_port: 3100
  log_level: info

common:
  instance_addr: 127.0.0.1
  path_prefix: /loki
  storage:
    filesystem:
      chunks_directory: /loki/chunks
      rules_directory: /loki/rules
  replication_factor: 1
  ring:
    kvstore:
      store: inmemory

schema_config:
  configs:
    - from: 2024-01-01
      store: tsdb
      object_store: filesystem
      schema: v13
      index:
        prefix: index_
        period: 24h

limits_config:
  retention_period: 720h     # 30 days
  max_query_series: 100000

compactor:
  working_directory: /loki/compactor
  delete_request_store: filesystem

ruler:
  alertmanager_url: http://localhost:9093

Step 4: Start the stack

sudo docker compose up -d
sudo docker compose logs -f

Verify:

curl http://localhost:3100/ready
# ready

Step 5: Grafana access

SSH tunnel:

ssh -L 3000:127.0.0.1:3000 user@CENTRAL_VPS_IP

Then http://localhost:3000 → login admin / AStrongPassword.

To expose in HTTPS, add Nginx in front with a Let's Encrypt certificate.

Step 6: Add Loki as a datasource

In Grafana:

Configuration → Data sources → Add data source
Search for Loki
URL: http://loki:3100 (Docker service name)
Save & test → must say "Data source is working"

Step 7: Install Promtail on a source VPS

On each VPS whose logs you want:

wget https://github.com/grafana/loki/releases/download/v3.0.0/promtail-linux-amd64.zip
unzip promtail-linux-amd64.zip
sudo mv promtail-linux-amd64 /usr/local/bin/promtail
sudo chmod +x /usr/local/bin/promtail

Create the config:

sudo nano /etc/promtail/config.yml

server:
  http_listen_port: 9080
  grpc_listen_port: 0

positions:
  filename: /var/lib/promtail/positions.yaml

clients:
  - url: http://CENTRAL_VPS_IP:3100/loki/api/v1/push
    # or via WireGuard: http://10.66.66.1:3100/loki/api/v1/push

scrape_configs:
  # Syslog
  - job_name: system
    static_configs:
      - targets:
          - localhost
        labels:
          job: syslog
          host: srv-web-01
          __path__: /var/log/syslog

  # Auth (SSH, sudo)
  - job_name: auth
    static_configs:
      - targets:
          - localhost
        labels:
          job: auth
          host: srv-web-01
          __path__: /var/log/auth.log

  # Nginx
  - job_name: nginx
    static_configs:
      - targets:
          - localhost
        labels:
          job: nginx_access
          host: srv-web-01
          __path__: /var/log/nginx/access.log
      - targets:
          - localhost
        labels:
          job: nginx_error
          host: srv-web-01
          __path__: /var/log/nginx/error.log

  # All Docker containers (auto-discovery)
  - job_name: docker
    static_configs:
      - targets:
          - localhost
        labels:
          job: docker
          host: srv-web-01
          __path__: /var/lib/docker/containers/*/*-json.log

  # Journald
  - job_name: journal
    journal:
      max_age: 12h
      labels:
        job: systemd-journal
        host: srv-web-01
    relabel_configs:
      - source_labels: ['__journal__systemd_unit']
        target_label: 'unit'

sudo mkdir -p /var/lib/promtail

Step 8: Systemd service for Promtail

sudo nano /etc/systemd/system/promtail.service

[Unit]
Description=Promtail
After=network.target

[Service]
Type=simple
User=root
ExecStart=/usr/local/bin/promtail -config.file=/etc/promtail/config.yml
Restart=always
RestartSec=10

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reload
sudo systemctl enable --now promtail
sudo systemctl status promtail

Check connection to Loki:

sudo journalctl -u promtail -f

Must read logs without network error.

Step 9: Explore logs in Grafana

In Grafana → Explore (compass icon) → datasource Loki.

Typical queries:

# All nginx access logs from host srv-web-01
{host="srv-web-01", job="nginx_access"}

# Errors only
{job="nginx_error"} |= "error"

# Logs with regex
{job="auth"} |~ "Failed password"

# Count 5xx errors per minute
sum(rate({job="nginx_access"} | json | status >= 500 [1m])) by (host)

# Top 404s
sum(count_over_time({job="nginx_access"} |= " 404 " [1h])) by (host)

Step 10: Parse structured logs (JSON, regexp)

Standard nginx logs

{job="nginx_access"}
  | regexp `(?P<remote_addr>[\d\.]+) - - \[(?P<timestamp>[^\]]+)\] "(?P<method>\w+) (?P<path>[^ ]+) HTTP/[\d\.]+" (?P<status>\d+) (?P<bytes>\d+)`
  | status >= 500

JSON logs (Node, Go apps)

{job="myapp"} | json | level="error"

Step 11: Grafana dashboards

Dashboards → Import → ID 13639 (community Loki + Promtail dashboard)
Select your Loki datasource
Import

You instantly get graphs: top hosts, log rate per job, errors, etc.

Step 12: Alerting (logs → alerts)

In Grafana → Alerting:

New alert rule
Loki datasource
Query:

sum(count_over_time({job="auth"} |= "Failed password" [5m])) by (host) > 20

Threshold: > 20 (= more than 20 SSH failures in 5 min)
Notification → Email, Discord, Slack, Telegram

Step 13: Retention and cleanup

Loki keeps logs per retention_period. For old data:

sudo docker compose exec loki ls -lh /loki/chunks/

The compactor (configured in loki-config.yml) auto-deletes old chunks.

Troubleshooting

Promtail doesn't push to Loki

sudo journalctl -u promtail -n 50

Common causes:

Firewall blocking port 3100 on central VPS
Wrong Loki URL (don't forget /loki/api/v1/push)
DNS not resolving

"context deadline exceeded"

Loki overloaded or Promtail too aggressive. Limit:

clients:
  - url: http://...
    batchwait: 1s
    batchsize: 1048576

No logs in Grafana

Check in Grafana → Explore → Loki that the datasource works. Then test with a general query {job=~".+"}.

Loki eats too much disk

Reduce retention_period. 7-30 days is usually enough.

Useful commands

# Promtail status
sudo systemctl status promtail
sudo journalctl -u promtail -f

# Test Promtail config
sudo promtail --check-syntax --config.file=/etc/promtail/config.yml

# Test Loki connectivity
curl http://CENTRAL_VPS_IP:3100/ready

# Promtail metrics (logs sent)
curl http://localhost:9080/metrics | grep promtail

# Force Promtail to reread positions
sudo systemctl restart promtail

# View Loki disk usage
sudo docker compose exec loki du -sh /loki

Conclusion

With Loki + Promtail you get:

Unified search across all your VPS from a single UI
10x more storage-efficient than ELK
Powerful LogQL queries, familiar if you know PromQL
Native alerting integrated with Grafana

Going further:

Migrate Loki to S3 / B2 storage to keep years of logs cheaply
Combine with Prometheus and Tempo for the full stack (metrics + logs + traces)
Use Vector or Fluent Bit as Promtail alternative (more transformations)

Resources

Loki official site: https://grafana.com/oss/loki/
Documentation: https://grafana.com/docs/loki/latest/
Promtail: https://grafana.com/docs/loki/latest/clients/promtail/
VeryCloud guide — Prometheus + Grafana: /docs/article/prometheus-grafana
VeryCloud guide — Docker Compose prod: /docs/article/docker-compose-prod
