NFS: native Unix file sharing

Introduction

NFS:

• Native Unix sharing protocol (since 1984)
• Better performance than SMB on Linux LAN
• Transparent mount: NFS share appears as local FS
• Versions: NFSv3 (UDP/TCP), NFSv4 (TCP only, more secure and performant)
• Auth: Unix uid/gid (NFSv3), optional Kerberos (NFSv4)

Use cases: Linux NAS, shared homes, VM storage (Proxmox, KVM), shared scientific data.

⚠️ NFS without Kerberos = source IP security only. Never on internet.

Prerequisites

• Linux server Debian / Ubuntu (NFS server)
• Linux clients that mount
• Dedicated LAN or VPN
• Root access

Step 1: Server installation

sudo apt update
sudo apt install -y nfs-kernel-server
sudo systemctl status nfs-server

Step 2: Create share directory

sudo mkdir -p /srv/nfs/share
sudo chown nobody:nogroup /srv/nfs/share
sudo chmod 755 /srv/nfs/share

For writable share:

sudo chmod 775 /srv/nfs/share

Step 3: Export the share

/etc/exports:

/srv/nfs/share     192.168.50.0/24(rw,sync,no_subtree_check,no_root_squash)
/srv/nfs/data      192.168.50.10(rw,sync,no_subtree_check) 192.168.50.11(rw,sync,no_subtree_check)
/srv/nfs/readonly  192.168.50.0/24(ro,sync,no_subtree_check,root_squash)

Important options:

• rw / ro: read-write / read-only
• sync: synchronous writes (on disk before ack). Safer. async faster but risky on crash.
• no_subtree_check: recommended, avoids costly checks
• root_squash (default): client root becomes nobody on server (security)
• no_root_squash: client root = server root (dangerous, only for legit cases)
• all_squash: all users become nobody

Step 4: Apply and start

sudo exportfs -ra
sudo systemctl restart nfs-server
sudo systemctl enable nfs-server

sudo exportfs -v

Step 5: Open firewall

NFSv4 uses only port 2049:

sudo ufw allow from 192.168.50.0/24 to any port 2049

NFSv3 needs multiple dynamic ports (rpcbind 111, mountd, nlockmgr). NFSv4 is preferable.

To pin NFSv3 ports:

sudo nano /etc/default/nfs-kernel-server

RPCMOUNTDOPTS="--port 32767"
STATDOPTS="--port 32765"

Step 6: Client install

sudo apt update
sudo apt install -y nfs-common

Step 7: Manual mount

sudo mkdir -p /mnt/nfs-share
sudo mount -t nfs4 192.168.50.10:/srv/nfs/share /mnt/nfs-share
df -h /mnt/nfs-share

You can read/write in /mnt/nfs-share.

Step 8: Auto mount via fstab

/etc/fstab:

192.168.50.10:/srv/nfs/share  /mnt/nfs-share  nfs4  defaults,_netdev,soft,intr,timeo=600  0  0

Client options:

• soft: server down doesn't block (fails after timeout)
• hard: blocks indefinitely (default, sometimes needed for VMs)
• _netdev: wait for network at boot
• timeo=600: RPC timeout in tenths of second
• nofail: don't block boot if mount fails

sudo mount -a

Step 9: Automount (autofs)

To mount on-demand only:

sudo apt install -y autofs
sudo nano /etc/auto.master

Add:

/mnt/nfs    /etc/auto.nfs --timeout=60

sudo nano /etc/auto.nfs

share    -fstype=nfs4,soft,intr    192.168.50.10:/srv/nfs/share
data     -fstype=nfs4,soft,intr    192.168.50.10:/srv/nfs/data

sudo systemctl restart autofs
ls /mnt/nfs/share    # auto mount

After 60s idle, autofs unmounts.

Step 10: Performance tuning

Buffer sizes

On client:

sudo mount -t nfs4 server:/path /mnt/point -o rsize=1048576,wsize=1048576,nconnect=8

• rsize / wsize: read/write block sizes (1 MB recommended)
• nconnect=8: 8 parallel TCP connections (NFSv4.1+, big perf boost)

Async write (risky but fast)

sudo mount -t nfs4 server:/path /mnt/point -o async

⚠️ Crash can lose writes. Only for tolerant use cases.

Perf test

dd if=/dev/zero of=/mnt/nfs-share/test.bin bs=1M count=1024 oflag=direct
dd if=/mnt/nfs-share/test.bin of=/dev/null bs=1M

Gigabit LAN: expect 110 MB/s+. 10 GbE: 800 MB/s+.

Step 11: NFSv4 with Kerberos (secure)

For strong auth, configure Kerberos and export with sec=krb5p:

/srv/nfs/secure   *(rw,sync,sec=krb5p)

Complex (needs KDC), useful in enterprise. For small LANs, stay with sec=sys + IP whitelist.

Step 12: Monitoring

Server side:

sudo nfsstat -s
sudo nfsstat -m
sudo showmount -e
sudo showmount -a 192.168.50.10

Client side:

nfsstat -c
mount | grep nfs

Logs:

sudo journalctl -u nfs-server -f
sudo dmesg | grep nfs

Troubleshooting

"mount.nfs: Connection refused"

Service not started or port blocked:

sudo systemctl status nfs-server
sudo ss -tunlp | grep 2049
sudo ufw status

"Permission denied" on write

uid mapping issue. Client and server must have same uid for user. Else use all_squash with anonuid:

/srv/nfs/share  *(rw,sync,no_subtree_check,all_squash,anonuid=1000,anongid=1000)

"Stale file handle"

File deleted or server restarted. Remount:

sudo umount -f /mnt/nfs-share
sudo mount /mnt/nfs-share

Slow performance

mount | grep nfs        # see active options

Increase rsize / wsize and try nconnect.

Server won't start

sudo exportfs -ra
sudo journalctl -u nfs-server

Check /etc/exports (syntax-sensitive, spaces matter).

Useful commands

# Server
sudo systemctl status nfs-server
sudo systemctl restart nfs-server
sudo exportfs -v
sudo exportfs -ra
sudo nfsstat -s
sudo showmount -e
sudo showmount -a

# Client
sudo mount -t nfs4 server:/path /mnt/point
sudo umount /mnt/point
sudo umount -f /mnt/point
mount | grep nfs
nfsstat -c
sudo rpcinfo -p server

# Diagnostic
sudo journalctl -u nfs-server -f
sudo dmesg | grep nfs
ss -tunlp | grep 2049

Conclusion

NFS is the standard for Linux/Unix file sharing:

• Better performance than SMB on Linux LAN
• Transparent mount
• Stable, mature, in kernel

Limits:

• IP / uid security (unless Kerberos)
• Not suitable for public LAN or internet without VPN
• Performance dependent on network (latency matters)

Going further:

• For multi-client write-intensive, consider GlusterFS or CephFS
• For HA NFS, look at DRBD + Pacemaker or commercial NAS
• For cross-platform, Samba remains more universal

Resources

• NFSv4 spec: https://datatracker.ietf.org/doc/html/rfc7530
• Linux NFS Wiki: https://linux-nfs.org
• Ubuntu NFS server guide: https://ubuntu.com/server/docs/network-file-system-nfs
• Debian wiki: https://wiki.debian.org/NFSServerSetup
