Introduction
Btrfs (B-tree filesystem):
- Copy-on-Write (CoW) like ZFS
- Lightweight snapshots and subvolumes
- Transparent compression (zstd, lzo, zlib)
- Stable RAID 0/1/10, partial RAID 5/6
- CRC32C checksums on data + metadata
- Online resize, defrag, balance, scrub
- In-place conversion from ext4
- Mainline Linux: GPL license, in kernel
vs ZFS:
- Btrfs is mainline (no DKMS)
- Btrfs handles mixed-size disks better
- ZFS is more mature for RAID-Z and perf
- ZFS has richer tooling ecosystem
Prerequisites
- Linux VPS / server Debian 12 / Ubuntu / openSUSE / Fedora
- Root access
- Available disks
Step 1: Install tools
Kernel module already included. For tools:
sudo apt update
sudo apt install -y btrfs-progs
btrfs --version
Step 2: Simple filesystem
sudo mkfs.btrfs /dev/sdb
sudo mkdir /mnt/data
sudo mount /dev/sdb /mnt/data
Persist in /etc/fstab:
UUID=xxx-yyy /mnt/data btrfs defaults,compress=zstd,space_cache=v2 0 0
sudo blkid /dev/sdb
Step 3: Multi-device (Btrfs RAID)
2-disk RAID1:
sudo mkfs.btrfs -m raid1 -d raid1 /dev/sdb /dev/sdc
sudo mount /dev/sdb /mnt/data
-m = metadata, -d = data.
4-disk RAID10:
sudo mkfs.btrfs -m raid10 -d raid10 /dev/sdb /dev/sdc /dev/sdd /dev/sde
RAID5/6 still considered experimental for data. Avoid in prod.
Step 4: Subvolumes
A subvolume = lightweight "sub-FS" you can snapshot independently:
cd /mnt/data
sudo btrfs subvolume create @home
sudo btrfs subvolume create @var
sudo btrfs subvolume create @backups
sudo btrfs subvolume list /mnt/data
Mount a subvolume:
sudo mount -o subvol=@home /dev/sdb /home
On openSUSE and similar: rootfs typically subvolume @, /home is @home.
Step 5: Snapshots
Snapshots are actually subvolumes linked to parent:
sudo btrfs subvolume snapshot /mnt/data/@home /mnt/data/@home-snap-2026-05-17
Read-only snapshot:
sudo btrfs subvolume snapshot -r /mnt/data/@home /mnt/data/@home-readonly
List:
sudo btrfs subvolume list /mnt/data
Delete:
sudo btrfs subvolume delete /mnt/data/@home-snap-2026-05-17
Step 6: Compression
sudo mount -o remount,compress=zstd:3 /mnt/data
Or in fstab:
UUID=xxx /mnt/data btrfs defaults,compress=zstd:3 0 0
zstd levels: 1 (fast, less compression) to 15 (slow, more). 3 is the default sweet spot.
Force compression on existing files:
sudo btrfs filesystem defragment -r -czstd /mnt/data
See compression ratio:
sudo compsize /mnt/data
Install compsize if missing:
sudo apt install -y compsize
Step 7: Quotas
sudo btrfs quota enable /mnt/data
sudo btrfs qgroup show -reF /mnt/data
sudo btrfs qgroup limit 50G /mnt/data/@home
⚠️ Btrfs quotas have non-trivial perf cost on large FS. Enable sparingly.
Step 8: Send / Receive (incremental backup)
Like ZFS, Btrfs can send a snapshot to another Btrfs FS.
Read-only snapshot required:
sudo btrfs subvolume snapshot -r /mnt/data/@home /mnt/data/@home-2026-05-17
Send:
sudo btrfs send /mnt/data/@home-2026-05-17 | ssh root@backup "btrfs receive /mnt/backup/"
Incremental:
sudo btrfs send -p /mnt/data/@home-2026-05-16 /mnt/data/@home-2026-05-17 | ssh root@backup "btrfs receive /mnt/backup/"
Step 9: Scrub and balance
Scrub: integrity check (checksums):
sudo btrfs scrub start /mnt/data
sudo btrfs scrub status /mnt/data
Monthly cron:
0 2 1 * * /usr/bin/btrfs scrub start -B /mnt/data
Balance: redistributes block groups, useful after adding/removing disks:
sudo btrfs balance start -dconvert=raid1 /mnt/data
sudo btrfs balance status /mnt/data
Step 10: Add / remove a disk
Add:
sudo btrfs device add /dev/sdd /mnt/data
sudo btrfs balance start /mnt/data
Remove (content migrated elsewhere):
sudo btrfs device remove /dev/sdb /mnt/data
Replace dead disk:
sudo btrfs replace start /dev/sdb /dev/sde /mnt/data
sudo btrfs replace status /mnt/data
Step 11: Snapper (snapshot automation)
Snapper automates Btrfs snapshots with timeline and rollback:
sudo apt install -y snapper
sudo snapper -c root create-config /
sudo snapper -c home create-config /home
See config:
sudo snapper -c root list
sudo snapper -c root status 1..2 # diff between snapshots 1 and 2
Rollback:
sudo snapper -c root rollback 5
On openSUSE, snapper integrates with GRUB to boot any snapshot.
Step 12: ext4 -> btrfs conversion
Btrfs can convert existing ext4 in place:
sudo umount /dev/sdb
sudo btrfs-convert /dev/sdb
sudo mount /dev/sdb /mnt/data
Old ext4 stays as subvolume ext2_saved. Once verified:
sudo btrfs subvolume delete /mnt/data/ext2_saved
⚠️ Backup first. Conversion is risky on large FS.
Troubleshooting
"no space left on device" but df shows free
Btrfs manages data and metadata separately. Often metadata full:
sudo btrfs filesystem df /mnt/data
sudo btrfs balance start -dusage=50 /mnt/data
Degraded performance (fragmentation)
On DB, VMs, heavy I/O files, CoW fragments. Solutions:
sudo chattr +C /var/lib/mysql # disable CoW for this dir
sudo btrfs filesystem defragment -r /var/lib/mysql
Mount fails after crash
sudo btrfs check /dev/sdb
sudo btrfs rescue super-recover /dev/sdb
⚠️ Don't use btrfs check --repair without backup, it's risky.
Scrub finds errors
Btrfs auto-repairs if RAID1+. Otherwise identifies corrupted files:
sudo btrfs scrub status -d /mnt/data
sudo dmesg | grep btrfs
Too many snapshots = slowness
Btrfs snapshots are cheap, but 10,000+ slows down. Snapper has retention policies:
sudo snapper -c root cleanup number
Useful commands
sudo mkfs.btrfs /dev/sdb
sudo btrfs filesystem show
sudo btrfs filesystem df /mnt/data
sudo btrfs filesystem usage /mnt/data
sudo btrfs subvolume list /mnt/data
sudo btrfs subvolume create / delete / snapshot
sudo btrfs device add / remove / replace
sudo btrfs device stats /mnt/data
sudo btrfs scrub start / status
sudo btrfs balance start / status
sudo btrfs filesystem defragment -r -czstd /mnt/data
sudo btrfs send / receive
sudo snapper -c root list
sudo snapper -c root create --description "before update"
sudo snapper -c root rollback 5
sudo btrfs check /dev/sdb
sudo dmesg | grep btrfs
Conclusion
Btrfs gives you:
- Snapshots/CoW in mainline kernel (no DKMS)
- Native compression and integrity
- Online conversion, resize, defrag
- Snapper integration for rollbacks
Limits:
- Experimental RAID5/6 (avoid for critical data)
- Quotas with overhead
- Mixed historical reputation (RAID5 issues), but stable in RAID1 / single / 10 configs
Going further:
- For servers with OS rollback, check openSUSE Tumbleweed or Garuda (btrfs + snapper integrated)
- Combine with borg or restic for offsite backups
- For VMs, disable CoW on images (
chattr +C)
Resources
- Official docs: https://btrfs.readthedocs.io
- Kernel wiki: https://btrfs.wiki.kernel.org
- Snapper: https://snapper.io
- Btrfs Debian wiki: https://wiki.debian.org/Btrfs
